Features that define a (ship) sail's shape and function

Sail components include the features that define a sail's shape and function, plus its constituent parts from which it is manufactured. A sail may be classified in a variety of ways, including by its orientation to the vessel (e.g. fore-and-aft) and its shape, (e.g. (a)symmetrical, triangular, quadrilateral, etc.). Sails are typically constructed out of flexible material that is shaped by various means, while in use, to offer an appropriate airfoil, according to the strength and apparent direction of the wind. A variety of features and fittings allow the sail to be attached to lines and spars. Whereas conventional sails form an airfoil with one layer of fabric, wingsails comprise a structure that has material on both sides to form an airfoil—much like a wing placed vertically on the vessel—and are beyond the scope of this article.

Classifications [ edit ]

Sails may be classified as either triangular, which describes sails that either come to one point of suspension at the top or where the sail comes to a point at the forward end, or quadrilateral, which includes sails that are attached to a spar at the top and have three other sides, or as square. They also may be classified as symmetrical (square sails and symmetric spinnakers) or asymmetrical (most other sails). Typically, asymmetrical sails perform better on points of sail closer to the wind than symmetrical sails and are designed for fore-and-aft rigs. Symmetrical sails perform best on points of sail that are further from the wind direction.[1][2]

Triangular [ edit ]

Triangular sails have names for each of three edges and three corners, explained below. Rigs with such sails include Bermuda, cutter, lateen and vessels with mixed sail plans that include jibs and other staysails. Most triangular sails are classified as asymmetrical and fore and aft; symmetric spinnakers are symmetrical triangular sails that are designed for off-the-wind use.[3]

Quadrilateral [ edit ]

Gaff, gunter, lug, junk and some sprit sails have four sides and are set fore and aft so that one edge is leading into the wind, forming an asymmetric quadrilateral shape. Naming conventions are consistent with triangular sails, except for the top edge and corners, as explained below.[4]

Square [ edit ]

A square rig is a type of sail and rigging arrangement in which the primary driving sails are carried on horizontal spars which are perpendicular, or square, to the keel of the vessel and to the masts—the sails themselves are not square but are symmetrically quadrilateral. These spars are called yards and their tips, beyond the last stay, are called the yardarms[5]. A ship mainly so rigged is called a square-rigger.[6]

Shape [ edit ]

Quadrilateral fore-and-aft sail Edges Corners Gaff-rigged Schooner.

The shape of a sail is defined by its edges and corners in the plane of the sail, laid out on a flat surface. The edges may be curved, either to extend the sail's shape as an airfoil or to define its shape in use. In use, the sail becomes a curved shape, adding the dimension of depth or draft.

Edges [ edit ]

The top of all sails is called the head, the leading edge is called the luff, the trailing edge is the leech, and the bottom edge is the foot. Head – The head is the upper edge of the sail, and is attached at the throat and peak to a gaff, yard, or sprit. For a triangular sail the head refers to the topmost corner. – The is the upper edge of the sail, and is attached at the throat and peak to a gaff, yard, or sprit. For a triangular sail the refers to the topmost corner. Leech – The aft (back) edge of a fore-and-aft sail is called the leech (also spelled leach ). [8] The leech is either side edge of a symmetrical sail—triangular or square. [a] However, once a symmetrical sail has wind blowing along its surface, whether on a reach or close-hauled, the windward leech may be called a luff (see below). – The aft (back) edge of a fore-and-aft sail is called the (also spelled ). The is either side edge of a symmetrical sail—triangular or square. However, once a symmetrical sail has wind blowing along its surface, whether on a reach or close-hauled, the windward leech may be called a (see below). Luff – The forward (leading) edge of a fore-and-aft sail is called the luff , and may be attached along a mast or a stay. [8] When on a reach, the windward leech of a spinnaker (symmetrical or not) is called the luff [11] and, when on a reach or close-hauled, the windward leech of a square sail may be called the luff or the weather leech . [a] – The forward (leading) edge of a fore-and-aft sail is called the , and may be attached along a mast or a stay. When on a reach, the windward leech of a spinnaker (symmetrical or not) is called the luff and, when on a reach or close-hauled, the windward leech of a square sail may be called the luff or the . Foot – The foot of a sail is its bottom edge.[8] On a fore-and-aft mainsail, the foot is often attached, at the tack and clew, to a boom; on a square sail to a spar by clews on both ends; if no boom or spar is present, the sail is said to be "loose-footed".

Roach [ edit ]

A fore-and-aft triangular mainsail achieves a better approximation of a wing form by extending the leech aft, beyond the line between the head and clew in an arc called the roach, rather than having a triangular shape. This added area would flutter in the wind and not contribute to the efficient airfoil shape of the sail without the presence of battens.[1] Offshore cruising mainsails sometimes have a hollow leech (the inverse of a roach) to obviate the need for battens and their ensuing likelihood of chafing the sail.[12] Roach is a term also applied to square sail design—it is the arc of a circle above a straight line from clew to clew at the foot of a square sail, from which sail material is omitted. The greater the departure from the straight line, the greater the "hollow" in the roach.[13][14] The roach allows the foot of the sail to clear stays coming up the mast, as the sails are rotated from side to side.[15]

Corners [ edit ]

1. Head 2. Reinforcement 3. Luff

4. Leech 5. Anti-UV covering

6. Headfoil attachment 7. Panel(s)

8. Telltales 9. Reinforcement

10. Tack 11. Leech control 12. Clew

13. Foot control 14. Foot

15. Furling marks Genoa jib , showing reinforcement and attachment points:1. Head 2. Reinforcement 3. Luff4. Leech 5. Anti-UV covering6. Headfoil attachment 7. Panel(s)8. Telltales 9. Reinforcement10. Tack 11. Leech control 12. Clew13. Foot control 14. Foot15. Furling marks

The names of corners of sails vary, depending on shape and symmetry.

Head – In a triangular sail, the corner where the luff and the leech connect is called the head.[8] On a square sail, the top corners are head cringles, where there are grommets, called cringles.[17] Peak – On a quadrilateral sail, the peak is the upper aft corner of the sail, at the top end of a gaff, a sprit or other spar. – On a quadrilateral sail, the is the upper aft corner of the sail, at the top end of a gaff, a sprit or other spar. Throat – On a quadrilateral sail, the throat is the upper forward corner of the sail, at the bottom end of a gaff or other spar. [18] Gaff-rigged sails, and certain similar rigs, employ two halyards to raise the sails: the throat halyard raises the forward, throat end of the gaff, while the peak halyard raises the aft, peak end. – On a quadrilateral sail, the is the upper forward corner of the sail, at the bottom end of a gaff or other spar. Gaff-rigged sails, and certain similar rigs, employ two to raise the sails: the raises the forward, throat end of the gaff, while the raises the aft, peak end. Clew – The corner where the leech and foot connect is called the clew on a fore-and-aft sail. On a jib, the sheet is connected to the clew; on a mainsail, the sheet is connected to the boom (if present) near the clew. [8] Clews are the lower two corners of a square sail. Square sails have sheets attached to their clews like triangular sails, but the sheets are used to pull the sail down to the yard below rather than to adjust the angle it makes with the wind. The corner where the leech and the foot connect is called the clew . [8] In the case of a symmetrical spinnaker, each of the lower corners of the sail is a clew. However, under sail on a given tack, the corner to which the spinnaker sheet is attached is called the clew , and the corner attached to the spinnaker pole is referred to as the tack . – The corner where the leech and foot connect is called the on a fore-and-aft sail. On a jib, the sheet is connected to the clew; on a mainsail, the sheet is connected to the boom (if present) near the clew. are the lower two corners of a square sail. Square sails have attached to their clews like triangular sails, but the sheets are used to pull the sail down to the yard below rather than to adjust the angle it makes with the wind. The corner where the leech and the foot connect is called the . In the case of a symmetrical spinnaker, each of the lower corners of the sail is a clew. However, under sail on a given tack, the corner to which the spinnaker sheet is attached is called the , and the corner attached to the spinnaker pole is referred to as the . Tack – The tack is the corner on a fore-and-aft sail where the luff and foot connect[8] and, on a mainsail, is located where the boom and mast connect.[8][21] On a square sail underway, the tack is the windward clew and also the line holding down that corner.
